CAST STEEL ECCENTRIC HALF BALL VALVE

Product Description The cast steel eccentric half ball valve uses the eccentric valve body, eccentric ball and valve seat. When the valve rod rotates, it will be automatically centered on the common
Port size
1-1/2"~20" (DN40~DN500)
Pressure
PN10-PN100 CL150-CL600
Structure
Eccentric half ball,side entry
Medium
Water,steam,oil,gas,etc.
Temperature
-29~150℃,-40~450℃
Body material
WCB,CF8,CF8M,CF3,CF3M etc.
Connection
Flange
Feature
Side entry or top entry is optional

Product Description

The cast steel eccentric half ball valve uses the eccentric valve body, eccentric ball and valve seat. When the valve rod rotates, it will be automatically centered on the common track. During the closing process, it will be tighter and tighter, completely achieving the purpose of good sealing. The ball of the valve is completely separated from the valve seat, eliminating the wear of the sealing ring, overcoming the problem that the traditional ball valve seat and the sealing surface of the ball are always worn. The non-metallic elastic material is embedded in the metal seat, and the metal surface of the valve seat is well protected. This product is especially suitable for steel industry, aluminum industry, fiber, micro solid particles, pulp, coal ash, petroleum gas and other media.

Standards Compliance

» Ball valve name: eccentric half ball valve

» Ball valve models :PQ340F, PQ340H

» Diameter range :DN40-DN500.

» Pressure range: PN10-PN100,150LB-600LB.

» Temperature range :-20℃-500℃.

» Transmission mode: manual, worm gear transmission, pneumatic, electric.

» Body material: cast steel, stainless steel

» Side entry eccentric half ball valve Connection: Flange.

» Design and manufacture: GB/T12237-1989;AP1608.

» nspection and testing: GB/T13927-1992;AP1598.

» Flange connection: JB/T79.1~2-1994;ASME/ANSIB16.10

Materials of main parts

NO.

Part name

Materail

1

BODY

WCB, CF8, CF8M

2

COVER

A105, 304, 316

3

SCREW

A105, 304, 316

4

BOLT

B7,B8,B8M

5

NUT

2H,8,8M

6

GASKET

Graphite,PTFE

7

BEARING

ASSEMBLY

8

STEM

2Cr13

9

BALL

WCB, CF8, CF8M

10

PLATE

A105, 304, 316

11

SEAT

PTFE, METAL SEAL

12

SCREW

A105, 304, 316

13

GASKET

Graphite,SS

14

STEM

2Cr13, 304, 316

15

BEARING

ASSEMBLY

16

SPLIT RING

1Cr18Ni9Ti

17

LOCATING

1Cr13

18

PACKING

Graphite

19

GASKET

0Cr18Ni9Ti

20

SCREW PLUG

2Cr13

21

SCREW PLUG

2Cr13

22

YOKE

WCB

23

BOLT

35CrMoA

24

NUT

Q245-A

25

GLAND

1Cr13

26

GLAND FLANGE

WCB

27

BOLT

35CrMoA

28

NUT

Q245-A

29

NUT

Q235-A

31

GASKET

0Cr18Ni9Ti

32

SCREW PLUG

2Cr13

Dimensions(mm) PN16

Size

L

D

K

d

f

C

Z-Фd

H

40

165

150

110

85

3

16

4-Ф18

280

50

178

165

125

100

3

16

4-Ф18

280

65

190

185

145

120

3

18

4-Ф18

280

80

203

200

160

135

3

20

8-Ф18

320

100

229

220

180

155

3

20

8-Ф18

370

125

254

250

210

185

3

22

8-Ф18

430

150

267

285

240

210

3

24

8-Ф23

510

200

292

340

295

265

3

26

12-Ф23

600

250

330

405

355

320

3

30

12-Ф26

690

300

502

460

410

375

4

30

12-Ф26

760

350

572

520

470

435

4

34

16-Ф26

830

400

610

580

525

485

4

36

16-Ф30

925

450

660

640

585

545

4

40

20-Ф30

1025

500

700

715

650

608

4

44

20-Ф34

1120

600

813

840

770

718

5

48

20-Ф36

1210
