Y TYPE PNEUMATIC BALL VALVE

Product Description

Y type pneumatic ball valve has each other into 120°, 135° two types of body structure, 120 Degree Y type pneumatic ball valve is flow path flat, small fluid resistance, strong flow capacity.When switching medium has no retention, 120 Degree Y type pneumatic ball valve will not cause secondary pollution.120 Degree Y type pneumatic ball valve is automatic control with electric actuators and pneumatic actuators.

Product Feature

» The flow channel is flat, the fluid resistance is small, the flow ability is strong.

» The medium has no retention and will not cause secondary pollution.

» Platform design in accordance with ISO5211 standard, 120 Degree Y type pneumatic ball valve can be ISO5211 standard actuator, direct connection.Good compatibility

» Silicon sol precision casting valve body, compact structure, high dimensional accuracy.The appearance is exquisite.

Performance parameter

» Pneumatic actuator: double action, single action normally closed, single action normally open

» Accessories:optional directional solenoid valve, limit switch, air filter pressure reducing valve, » electric positioner, handwheel mechanism

» Voltage:AC220V, AC110V, AC380V, DC12V, DC24V, DC110V

» Nominal diameter: DN50-350mm

» Nominal pressure: 1.6mpA-2.5mpa

» Suitable temperature:PTFE:-30~+180℃, hard seal

» Connection mode: flange type

» Valve body structure: Y 120°, Y 135°, Y 45°

» Body material: WCB, 304, 316, 316L or others

» Valve ball material: WCB, 304, 316, 316L or others

» Seat lining: PTFE, PPL, hard seal

» Medium:Suitable for medium powder
