3 PIECE HIGH PLATFORM BALL VALVE

Product Description

The high platform three piece internal thread ball valve adopts the split structure design, and the ball valve has a fire-proof structure. The high platform ball valve adopts the ISO5211 direct installation actuator platform design, and there is an anti-static device between the balls; Explosion proof design of valve rod; The ball valve has double-layer valve stem packing, which meets the requirements of valve stem leakage test; The design of double disc spring piece automatic compression packing; The high platform three piece internal thread ball valve is applicable to various pipelines with PN1.0 ~ 12.5mpa and working temperature of -29 ~ 180 ℃ (the sealing ring is reinforced polytetrafluoroethylene) or -29 ~ 300 ℃ (the sealing ring is aligned polystyrene) for cutting off or connecting the medium in the pipeline. The 3pc high platform three piece internal thread ball valve is made of different materials and can be applied to various media such as water, steam, oil, nitric acid, acetic acid, etc.

Structural Features

Product name: 3 PIECE HIGH PLATFORM BALL VALVE

Size: 1/2" -4" (DN15-DN100)

Material: SS304, SS316(CF8, CF8M)

Pressure: 1000PSI, PN16

Suitable medium: water, oil, air and some corrosive liquid etc(WOG)

Temperature Range: -20-250 degree C

Connection: F/F threaded

Type of thread: NPT, BSPT, BSP, PT, DIN2999 ETC

Sealing: PTFE, RPTFE, PPL ETC

Materials of main parts

Dimensions(mm)
